The main application of diamond powder

Release time:

2023-06-24

As a kind of super hard abrasive, diamond powder has incomparably superior grinding ability, which has been paid more and more attention by the industrial developed countries. The grinding ability of diamond powder includes the grinding ability of the workpiece and its own wear resistance and crushing resistance, depending on its microhardness, particle size, strength, particle size, and thermal and chemical stability. To sum up, diamond powder used as abrasive has three aspects; (1) Used in the manufacture of resin-bonded tools, metal-bonded tools, and plating tools. (2) for industrial, scientific and medical precision or polishing of various precision components. (3) as a fine abrasive for mold processing, gem polishing processing, gem bearing processing and manufacturing. In addition to the application of diamond powder as a grinding material, another major use is used as a functional material. For example, the use of its thermal properties and electrical properties. By mixing diamond fine powder into thermosetting resin polymer, cellulose, phenolic resin or ceramic sheet, a new material having improved thermal conductivity and reduced thermal expansion can be produced. The diamond powder mixed to the metal sheet, such as sheet or stainless steel sheet can be made with high thermal conductivity, low thermal expansion and light weight of the new sheet material, in the electronics industry can be made into high-density high-energy devices for thermal control. From the form of diamond used as grinding materials, according to the relevant data published figures, the world's industrial consumption of more than 60% of diamond powder is used to make diamond plaster, diamond powder mixture and diamond powder grinding fluid.

   As a kind of super hard abrasive, diamond powder has incomparably superior grinding ability, which has been paid more and more attention by the industrial developed countries. The grinding ability of diamond powder includes the grinding ability of the workpiece and its own wear resistance and anti-crushing ability, depending on its microhardness, particle size, strength, particle shape and thermal and chemical stability. To sum up, diamond powder used as abrasive has three major aspects:

(1) Used in the manufacture of resin bonding tools, metal bonding tools and electroplating tools;

(2) for industrial, scientific and medical precision components of fine grinding or polishing processing;

(3) as a fine abrasive for mold processing, gem polishing processing, gem bearing processing and manufacturing.

In addition to the application of diamond powder as a grinding material, another major use is used as a functional material. For example, the use of its thermal properties and electrical properties. By mixing the diamond fine powder into a thermosetting resin polymer, cellulose, phenol resin or ceramic sheet, a new material having improved thermal conductivity and reduced thermal expansion can be produced. The diamond powder mixed into the metal sheet, such as nickel or stainless steel sheet can be made with high thermal conductivity, low thermal expansion and light weight of the new sheet material, in the electronics industry can be made into high-density high-energy devices for thermal control.

   From the form of diamond used as grinding materials, according to the relevant data published figures, the world's industrial consumption of diamond powder more than 60% is used to make diamond plaster, diamond powder mixture and diamond powder grinding fluid.
